Applications: cobblestone sand, machined sand, quartz sand, limestone sand
Materials: river pebbles, limestone, granite, basalt, river pebbles, iron ore, marble, etc.
Feed particle size: 0-50mm
Processing capacity: 70-640T/H
The 5X Sand Maker/Crusher is the third generation of sand making equipment produced by LiMing Heavy Industry based on years of sand production experience and the introduction of German advanced technology. The machine adopts new manufacturing technology, unique structural design, and the finished product is a cube, no Tension and cracks, grain shape is quite good. 5X sand making machine can professionally process pebbles. It is an efficient and energy-saving cobblestone sand making equipment. It is 50% more energy-saving than traditional sand making machines. It is currently the world’s advanced sand making equipment and recommended equipment of China Sandstone Association.
1、5X sand making machine has a double overload protection system to make the machine safe and reliable.
2. The cobblestone sand making machine has a high degree of automation, low energy consumption, and large crushing ratio.
3, the third generation of sand making machine has a plastic function, the product into a cube.
4, the new sand making machine finished fine particle size, in line with national standards for sand.
5, easy to install, easy to operate: equipment, light weight, a variety of installation methods, removable installation; installation, repair and maintenance simple, easy operation and use.
6、Excellent launching port and internal smoother curve design reduce the flow resistance of materials and greatly improve the material throughput.
7, bearing selection of Japan, Sweden, the United States and other international brands.
8, in the production process, the stone can form a protective bottom layer, the body without wear and durable.
Main technical parameters:
Model | VSI5X7615 | VSI5X8522 | VSI5X9532 | VSI5X1145 | |
Throughput capacity (t/h) | Center and Ring feeding | 150~280 | 240~380 | 350~540 | 500~640 |
Center feeding | 70~140 | 120~190 | 180~280 | 250~360 | |
Max. Feed Size (mm) | Soft material | <35 | <40 | <45 | <50 |
Hard material | <30 | <35 | <40 | <45 | |
Rotation speed (r/min) | 1700~1900 | 1500~1700 | 1300~1510 | 1100~1310 | |
Power of double motor (KW) | 2×75 (100) | 2×110 (150) | 2×160 (220) | 2×220 (300) | |
Overall dimension L×W×H (mm) | 4100×2330×2300 | 4140×2500×2700 | 4560×2600×2900 | 5000×2790×3320 | |
Weight (t) | 8.6 | 11.8 | 17.5 | 27.5 | |
Thin oil lubrication station | Power for double oil pump | 2×0.25(0.33) | |||
Safety | TO make sure the supply of the oil with double oil pump; stop working without oil or hydraulic pressure; temperature falls when the water cool;start the motor by heating it in winter | ||||
Power for oil box heater | 2 KW | ||||
Overall dimension L×W×H (mm) | 820×520×1270 |
Note: Capacity depends on crushing limestone, material size, moisture and features also affect capacity.
