Application areas: gravel yard extraction, smashing, concrete mixing station, sand pebbles, quartz sand, power plant desulfurization and so on.
Materials: Limestone, granite, basalt, river pebble, cobblestone, iron ore, schist, etc.
Feed particle size: 0-275 mm
Productivity: 27-660T / H
The single-cylinder hydraulic cone crusher is a new type of crushing equipment with high crushing efficiency, low production cost and excellent finished granularity in the crushing machinery equipment. The crusher is mainly used for crushing, fine crushing and ultra-fine crushing. in. They are widely used in metallurgy, construction, automotive, chemical and building materials industries, and are suitable for the crushing of high hardness, high abrasive ores and rocks. Especially widely used for the crushing of metal ore and construction gravel.
1, High efficiency: single-cylinder hydraulic cone crusher is a combination of higher speed and stroke, so that the hydraulic cone crusher rated power and through the ability to greatly improve and improve the crushing ratio and production efficiency
2, Good discharge shape: hydraulic cone crusher using a unique crushing cavity shape and the principle of laminating crushing, resulting in inter-particle crushing effect, so that the proportion of the finished cube is significantly higher, more uniform particles. .
3, The production capacity: The hydraulic cone crusher crushing stroke, crushing speed and the perfect combination of the shape of the crushing cavity design, so that the machine in the case of the same diameter of the dynamic cone, the output than the old crusher 35% ~ 60%.
4. Simple and easy to operate: modern control system, and provide manual control, constant discharge port control, constant power control and other operating modes for users to choose.
| Model | Cavity | Maximum feed size(mm) | CSS min-max(mm) | Capacity(tph) | Power KW(HP) | Dimension (L×W×H) (mm) | Weight (t) |
| HST100 | S1(Extra Coarse) | 240 | 22-38 | 85-170 | 90(125) | 1535×1275×2710 | 9.6 |
| S2(Medium Coarse) | 200 | 19-32 | 70-130 | ||||
| HST160 | S1(Extra Coarse) | 360 | 25-54 | 120-345 | 132(175) | 2045×1635×3040 | 15.5 |
| S2(Medium Coarse) | 300 | 22-48 | 105-305 | ||||
| S3(Coarse) | 235 | 19-48 | 90-275 | ||||
| HST250 | S1(Extra Coarse) | 450 | 35-54 | 255-605 | 220(300) | 2675×2550×3940 | 28 |
| S2(Medium Coarse) | 400 | 29-51 | 215-515 | ||||
| S3(Coarse) | 300 | 25-51 | 190-490 | ||||
| HST315 | S1(Extra Coarse) | 560 | 41-76 | 335-1050 | 315(400) | 3110×2945×4480 | 43.5 |
| S2(Medium Coarse) | 500 | 38-70 | 305-895 | ||||
| Model | Cavity | Maximum feed size(mm) | CSS min-max(mm) | Capacity(tph) | Power KW(HP) | Dimension (L×W×H) (mm) | Weight (t) |
| HST100 | H1(Fine) | 135 | 10-32 | 45-130 | 90(125) | 1540×1280×2300 | 7.5 |
| H2(Medium Fine) | 65 | 8-19 | 35-80 | ||||
| H3(Extra Fine) | 38 | 4-16 | 27-60 | ||||
| HST160 | H1(Fine) | 185 | 13-38 | 66-210 | 132(175) | 2000×1550×2600 | 10 |
| H2(Medium Fine) | 90 | 10-32 | 65-165 | ||||
| H3(Extra Fine) | 50 | 6-25 | 48-105 | ||||
| HST250 | H1(Fine) | 215 | 16-44 | 110-395 | 220(300) | 2315×1830×2940 | 19.5 |
| H2(Medium Fine) | 110 | 13-38 | 115-340 | ||||
| H3(Extra Fine) | 70 | 8-32 | 90-255 | ||||
| HST315 | H1(Fine) | 275 | 16-51 | 170-665 | 315(400) | 2740×2200×3590 | 28.5 |
| H2(Medium Fine) | 135 | 16-38 | 190-505 | ||||
| H3(Extra Fine) | 65 | 13-22 | 205-320 | ||||
| HST560 | H1(Fine) | 300 | 22-70 | 448-1331 | 560(750) | 3300×2600×4463 | 51 |
| H2(Medium Fine) | 155 | 19-70 | 400-1098 | ||||
| H3(Extra Fine) | 80 | 10-44 | 280-669 | ||||
| HST750 | H1(Fine) | 370 | 25-70 | 480-2500 | 630(850) | 3800×3100×5305 | 80 |
| H2(Medium Fine) | 195 | 22-70 | 552-1115 | ||||
| H3(Extra Fine) | 80 | 10-51 | 364-790 |
