QH332 Cone Crushing High Efficiency Multifunctional Plant

The QH332 is a tracked stand-alone cone crusher with an on-board diesel engine.The QH332 cone crusher is suitable for a wide range of crushing operations, especially where an efficient, flexible and mobile crushing solution is required. Its design allows the plant to easily adapt to different working environments and material types, thus meeting the diverse needs of customers.

Materials Sand and gravel quarry, concrete mixing plant, dry mortar, power plant desulphurisation, quartz sand, etc.
Application River pebbles, granite, basalt, iron ore, limestone, quartzite, pyroxene, iron ore, gold ore, copper ore, etc.
Capacity 220 TPH

CONTACT NOW down load to pdf

Product Details

Product Tags

The QH332 Cone Crusher is a tracked, self-contained cone crusher that can be detached/attached without the use of additional lifting equipment, offering versatility such as a 1, 2 or 3 way split screen machine as well as a highly efficient cone crusher. Equipped with the world's leading CH430 cone crusher as the core technology, the technology is equipped with a water jacket system that provides CSS adjustment at the touch of a button. The automatic setting adjustment system optimises production and tracks liner wear, facilitating planning of liner changes and minimising production interruptions.The QH332 Cone Crusher plays an important role in crushing operations due to its advanced technology, high production capacity and flexible applicability.

QH332 Cone Crushing High Efficiency Multifunctional Plant Applications

QH332 cone crusher shows wide application value in many fields.
In the field of construction, QH332 cone crusher is the key equipment for the production of building materials, which can effectively crush the raw materials such as cement, concrete, building sand and gravel to medium fineness, providing strong support for the production of high-quality building materials.
In road and bridge construction, the crusher also plays an irreplaceable role. It is capable of crushing stone materials finely, providing high-quality base materials for road construction, thus significantly improving the construction quality of road and bridge projects.
In addition, water conservancy projects are also inseparable from the QH332 cone crusher help. It can easily crush large stone materials, providing the required stone materials for the construction of water conservancy projects and ensuring the smooth progress of the projects.
In the field of mining, QH332 cone crusher shows its powerful crushing ability. It is especially suitable for all kinds of hard minerals in the fine crushing operations, such as iron ore, limestone, etc., can easily meet the demand for products with different particle size requirements.
Not only that, the application scope of QH332 Cone Crusher also extends to many fields such as chemical industry, energy and so on. It is capable of medium and fine crushing of all kinds of ores and rocks with pressure below 350 MPa and hardness ≤5~16 on the Platts scale, showing high versatility and adaptability.

QH332 Cone Crushing High Efficiency Multifunctional Plant Advantages

‌QH332 Cone Crusher, as a model of the world's leading technology design, not only has the remarkable features of large crushing ratio and high efficiency, but also shows its excellent performance and advantages in many aspects.
This crusher can easily cope with the task of crushing large rocks and quickly reduce them to small rocks, gravel or rock dust. Its powerful crushing capacity makes it able to meet the diversified needs of medium and fine crushing of all kinds of ores and rocks, whether it is granite with high hardness or materials with high humidity, all of which can be processed efficiently.
The crushed product has uniform particle size and neat shape, which is thanks to the unique inter-granular laminar crushing effect of the cone crusher. Through this action, the materials are evenly squeezed and ground in the crushing chamber, thus obtaining the ideal crushing effect. At the same time, users can also adjust the size of the discharge opening to precisely control the particle size of the finished product to meet different application scenarios and user-specific requirements.
In terms of energy consumption, QH332 Cone Crusher also performs well. The electric motor it adopts is not only powerful enough, but also more economical in terms of power consumption, effectively reducing energy consumption and saving costs. In addition, its design optimises the force structure of the equipment, improves the running speed, and supports the two ends of the main shaft, which further reduces energy consumption and improves the overall performance.
In terms of maintenance, the QH332 cone crusher also shows great convenience. All its components can be disassembled and assembled from the top and sides, greatly simplifying the maintenance process of the equipment. At the same time, the equipment is easy to operate and install, with low vibration and low noise at the foundation, and it is also more convenient to replace the liners on a daily basis, which provides great convenience for the long-term use of users.
It is worth mentioning that QH332 is also equipped with advanced hydraulic system and protection devices. Such as two-way over-iron release hydraulic cylinder and over-iron protection device, etc. The existence of these devices ensures the stable operation and easy maintenance of the equipment. When encountering non-crushable materials, the hydraulic system can automatically release the pressure to prevent equipment damage; while the over-iron protection device can effectively remove non-crushable materials in the crushing chamber to protect the machine from damage.

QH332 Cone Crushing High Efficiency Multifunctional Plant Working Principle

The working principle of QH332 Cone Crusher is closely centred on the core mechanism of the cone crusher, i.e. through the rotating cone and its internal crushing chamber, combined with the squeezing, impacting and grinding effects of the moving cone, the material is efficiently crushed to the required size.
During operation, the material first enters the crushing chamber of the crusher through the feed opening. This inlet is cleverly designed at the top of the crushing chamber, which facilitates the smooth feeding of materials through the feed hopper or vibrating feeder.
With the start of the motor, the moving cone of the QH332 Cone Crusher begins to rotate. Driven precisely by the eccentric shaft, the moving cone moves in a yawning motion along the surface of the stationary cone. During this process, the moving cone is sometimes close to the fixed cone and sometimes moderately away, creating a dynamic crushing environment.
When the moving cone is close to the fixed cone, the material is tightly squeezed between the two, and at the same time is subjected to the strong impact and grinding effect of the moving cone, so as to effectively realise the crushing. This crushing process continues in the annular crushing chamber formed by the moving cone and the fixed cone, where the material undergoes continuous squeezing, impacting and bending until it reaches the required particle size.
After the crushing process is completed, the material is discharged through the discharge opening at the bottom of the crushing chamber. The design of this outlet is very flexible and its size can be adjusted according to the actual needs to ensure that the size of the crushed material meets the specific requirements. When the moving cone leaves the fixed cone, the crushed material is naturally discharged from the discharge opening at the bottom of the cone under the effect of gravity, completing the whole crushing process.
QH332 Cone Crusher not only has high efficiency and precise crushing ability, but also shows strong adaptability. It can easily cope with a variety of different working surfaces and environments, and whether it is dealing with hard ores or soft materials, it can play a stable performance and provide strong support for a variety of crushing tasks.
