Stone Crusher Equipment LT96 Mobile Jaw Crusher

In addition, the equipment is also equipped with an advanced E dust removal system and dust prevention device, which realizes the offline automatic dust cleaning function, effectively reduces dust emissions during the production process, and achieves excellent environmental protection effects. This feature enables the LT96 mobile jaw crusher to maintain its competitive advantage today when environmental protection requirements are becoming increasingly stringent.

Materials Basalt, limestone, quartz, diabase, iron ore, etc.
Application Coal mining, dry mortar, power plant desulfurization, concrete mixing station, etc.
Capacity 120-250 t/h

CONTACT NOW down load to pdf

Product Details

Product Tags

As a device designed for primary crushing, the LT96 mobile jaw crusher does show its unique advantages. It is cleverly mounted on crawlers, allowing the equipment to be easily moved within a quarry or construction site, and can also be conveniently transported between construction sites via low-chassis trucks. This feature undoubtedly greatly improves the flexibility and scope of application of the equipment.
For small-scale aggregate production and demolition waste crushing on construction sites, the LT96 is undoubtedly an ideal choice. Its core component, the mature jaw crusher, adopts the working principle of simulating the movement of the two jaws of animals, and realizes the up and down movement of the movable jaw through the drive of the motor. This design not only makes the crushing process more efficient, but also ensures the stability and reliability of the crushing effect.
During the crushing process, when the movable jaw rises, the angle between the toggle plate and the movable jaw becomes larger, pushing the movable jaw plate to approach the fixed jaw plate, and the material is squeezed, rubbed, and crushed between the two jaw plates, achieving multiple crushing. When the movable jaw moves downward, the angle between the toggle plate and the movable jaw becomes smaller, and the movable jaw plate leaves the fixed jaw plate under the action of the pull rod and the spring, and the crushed material is discharged freely through the discharge port at the bottom of the jaw cavity under the action of gravity. With the continuous rotation of the motor, the movable jaw continuously performs periodic crushing and discharging, thus realizing mass production. In addition, the equipment is also equipped with an advanced E dust removal system and dust prevention device, which realizes the offline automatic dust cleaning function, effectively reduces dust emissions during the production process, and achieves excellent environmental protection effects. This feature enables the LT96 mobile jaw crusher to maintain its competitive advantage today when environmental protection requirements are increasingly stringent.

Stone Crusher Equipment LT96 Mobile Jaw Crusher Applications

In mining projects, the LT96 mobile jaw crusher can crush various hard ores and rocks into particles of appropriate size, providing raw materials for subsequent mineral processing and smelting. Its large crushing ratio and uniform product particle size make this equipment very popular in the mining industry.
The LT96 mobile jaw crusher can be used in the production of building materials, such as crushing limestone, granite, etc. into raw materials for concrete, mortar, etc. It can also crush construction waste into usable recycled materials, promoting the green development of the construction industry. In addition, due to its compact structure, the LT96 mobile jaw crusher is very suitable for small-scale aggregate production and construction waste crushing at the construction site.
In road projects such as highways and railways, the LT96 mobile jaw crusher can crush various stones for roadbed and pavement paving. Its efficient and reliable working performance ensures the smooth progress of road projects.
In chemical production, the LT96 mobile jaw crusher can be used to crush raw materials such as coal, sulfur, and phosphate rock, providing a stable and reliable supply of raw materials for chemical production.
With the improvement of environmental awareness, LT96 mobile jaw crusher also plays an important role in the field of environmental protection. It can crush urban garbage, scrap iron and other waste into smaller particles, which is convenient for garbage disposal and resource recycling. In particular, its noise reduction and dust suppression system allows the equipment to carry out crushing operations in areas close to the public, complying with stricter noise and dust control regulations.

Stone Crusher Equipment LT96 Mobile Jaw Crusher Advantages

Compact structure and flexible movement

The equipment's compact design makes it easy to move across ports or in tight spaces, and can even easily obtain a permanent transport license in some countries. Its excellent mobility allows it to easily handle various complex working conditions and job sites.

Efficient crushing and outstanding performance

The equipment is equipped with a mature jaw crusher, which has strong crushing capacity and can quickly crush materials to the required particle size. The crushing ratio is large and the product particle size is uniform, which perfectly meets the diverse crushing needs.

Intelligent control, simple and fast

The automatic control system fully optimizes the crushing effect and realizes convenient one-button start and stop operations. The system's built-in troubleshooting function and multiple parameter selections effectively improve crushing efficiency and operation convenience. At the same time, the active discharge port control function can automatically adjust the crusher discharge port according to actual conditions, effectively avoiding problems such as blockage or reduced crushing efficiency.

High durability and easy maintenance

The equipment adopts a solid pin-bolted frame structure, which significantly improves the crusher's durability against impact loads. The spacious maintenance platform and easy-to-reach jaw crusher maintenance points make daily operations safer and simpler.

Environmentally friendly, energy-saving, compliant and efficient

The equipment operates with low noise and dust pollution is effectively controlled, fully complying with more stringent noise and dust management regulations. At the same time, the equipment has significant energy-saving effects, helping to significantly reduce production costs and energy consumption.

Wide range of applications

This equipment is widely used in mining, construction, highways, railways and other fields. It can handle various metal and non-metallic ores, construction waste, waste concrete and other materials, showing strong versatility and adaptability.

Stone Crusher Equipment LT96 Mobile Jaw Crusher Working Principle

The working principle of the LT96 mobile jaw crusher is quite ingenious. The eccentric shaft starts to rotate slowly through the motor-driven belt and pulley, providing the initial power source for the crusher. As the eccentric shaft rotates, the movable jaw also begins its up and down movement. When the movable jaw rises, the angle between the toggle plate and the movable jaw gradually increases, pushing the movable jaw plate slowly towards the fixed jaw plate. Between the two jaw plates, the material is subjected to multiple forces such as squeezing and rubbing until the pressure exceeds the limit, and crushing occurs. When the movable jaw moves downward, the angle between the toggle plate and the movable jaw gradually decreases, and the movable jaw plate separates from the fixed jaw plate under the elastic force of the pull rod and the spring. At this time, the crushed material will be pulled out freely through the discharge port at the bottom of the jaw cavity under the traction of gravity. As the motor continues to rotate, the movable jaw continuously repeats the periodic action of crushing and discharging, thus ensuring that the LT96 mobile jaw crusher can continuously and efficiently process various types of materials.
