jaw crusher

jaw crusher Details

Product Tags

OUTPUT SIZE: 40mm to 350mm
PRODUCTION CAPACITY: Up to 800TPH
1.We have been a leading manufactuer of jaw crushers for over 20 years, which is one of our major business. Jaw Crusher can be used to crush various mineral stones and bulk materials to medium size. There are two types: coarse crushing and fine crushing, it will be the ideal equipment for primary crushing. Jaw Crusher is widely used in mine, metallurgy, the building, road and railroad construction, hydraulic construction, chemical industry, fire-proofing material and ceramics.
Jaw crusher mainly consists of frame, eccentric shaft, jaw, connecting rod, the adjustment mechanism with the latch spring and other components.

2 Features
1. crushing chamber depth and no dead zone, improve the ability to feed and yield;
2. its crushing ratio, uniform particle size;
3. Gasketed nesting population adjustment device, reliable and convenient, adjustment range, increase the flexibility of the device;
The lubrication system is safe and reliable, easy to replace parts, small maintenance workload;
5. The structure is simple, reliable, low operating costs.
6. Equipment Energy: single saving 15% to 30%, saving the system more than doubled;
7. nesting population adjustment range, can meet the requirements of different users;
8. Low noise, less dust.
3 Intended use
1, the series crusher is mainly used in metallurgy, mining, chemical, cement, construction, refractory and ceramics and other industrial departments for secondary and tertiary crushing of various medium hard ore and rock with.
2, the series crusher is most suitable crushing compression strength not higher than 300MPa (MPa) of various soft and hard ore, the largest block of the material to be broken is not greater than the prescribed technical parameters
4 Features:
1, using the world-class manufacturing processes, selection of the most high-end production of materials.
2. More advanced movable jaw assembly, to make it more durable. Movable jaw assembly adopts high-quality cast steel structure, and by two large steel flywheel drive. Further heavy eccentric shaft has also adopted forging billet for processing, which were all making the JCE series jaw crusher with exceptional reliability.
3, the bearing using integrated cast steel structure.
5 works
Jaw crusher works for the song moving extrusion type, its working principle is: Motor drive belt and pulley, through the eccentric shaft to move up and down movement of the jaw, when the movable jaw rises between toggle plate and moving jaw angle becomes larger, push moving jaw plate close to the fixed jaw plate, simultaneously with the material being crushed or split pieces to achieve the purpose of crushing; when the movable jaw down, the angle between toggle plate and moving jaw becomes small, the role of the lever, the spring movable jaw plate By leaving the fixed jaw plate, then the crushed material from the crushing chamber discharge port. With the motor continuously rotating and mobile jaw crusher for periodic motion crushing and waste material, to achieve mass production. Get Price >>
