The deep rotor is about 50% greater than that of normal rotor, which means there is a greater space between distributor and feed eye ring, as well as between the upper and lower wearing plates. Capacity in this way improves at least 30% then the traditional VSI crusher.

Rotor is the heart of VSI, the success of  VSI Crusher attributes to the application of new technology for its deep rotor.

Production Process

Raw material of 12"-14" size is primarily crushed by the client’s jaw crusher down to 2 and then enter into our hammer crusher PC400×300, after secondary crushing, it will be less than 0.4, and discharged to bucket elevator. The elevator sends the material to storage hopper, there’s a vibrating feeder under the hopper, the feeder feeds material to main unit of mill evenly and continuously.

When the material being ground in the mill, the blower blows the powder to classifier, the classifier impeller is rotating at adjustable speed which is controlled from control cabinet, as per client’s requirement, powder less than 10 micron will be separated by classifier, and bigger powder falls down, being reground over and over again. 10micron and less than 10micron powder then go to the cyclone collector with the air from blower and be collected in the cyclone collector. Powder will be discharged from the discharge valve to become the final products. The bag filter will clean the outgoing air to protect the environment.

Case Study

A mining company inIndiaintends to produce calcium carbonate powder with fineness of 5-10 micron; required capacity is 1.0 ton per hour. They had a Raymond mill which can not meet their desired fineness. Their stone input size is 12"-14". They have a primary 16"×10" jaw crusher. Based on customer’s situation, we had recommended full set of XZM221 Ultrafine mill for their solution. The mill was installed since 2009 and is running perfect inIndianow.
