Overview of mining Coarse Powder Mill
Coarse Powder Mill is using as a kind of milling and sand processing equipment . It is developed after the requirements of industrial needs . It is ideal in production lines of grinding quartz sand, silica sand and other sand . For better usage of final products , the machine can be adjusted to process raw materials .
Feature of mining Coarse Powder Mill
1. Low electricity consumption in the working process .
2. High capacity and large crushing ratio .
3.Compact structure and even granule .
4. Wide applicability in different fields . Easy to maintain and operate .
Principle of mining Coarse Powder Mill
The Coarse Powder Hammer Mill main parts are : rotor, iron bearing, grate bars and related small parts . The rotor rotates through motor . Large centrifugal force is working to grind materials . After the steps , powder with the right size we require falls down , then come out from discharging opening .
parameter of mining Coarse Powder Mill
| Name | Parameter | Remark | |
| Model | Power | ||
| Model | MSB1004 | ||
| Roller quantity | 4pcs | ||
| Max. feeding size | <30mm | Too hard material<20mm | |
| Product size | 70-90%<2mm | Adjustable, check below | |
| Capacity | 8-15ton/hour | Relative to average size and hardness of feeding material | |
| Main motor power | 37-45kW | Use small motor if use fine material and want low capacity | |
| Main motor model | Y2-225M-4 | 45 kW | |
| Overall size（L×W×H） | 1.87×1.5×2.58(m） | Including main motor, decelerator and main unit | |
| Largest single pc weight | 900kg | ||
| Total weight（excluding electricity control cabinet） | 8ton | Decelerator weight 1.7 ton | |
| Jaw crusher of fine crushing | PEX150×750 | 15kW | |
| Bucket elevator | TH250 | 3kW | Speed≥1.2m/s |
| Electromagnetic Vibrating feeder | GZ3 | 0.2kW | Distance between inlet and outlet 1000 |
