Overview of mining LM Series Vertical Mill
LM Series Vertical Mill is using top technology of world class level , it is a new type advanced machine. LM Series Vertical Mill can crush and grind many kinds of materials including granular and powdered materials.Cement, power, chemical industry are in great need of good quality grinding mills .
Feature of mining LM Series Vertical Mill
1. LM Series Vertical Mill system joins crushing, drying, grinding and classifying together.The machine can be installed outside and saves occupation area.
2. It saves energy. By regulating the air temperature while working .
3. It is able to reduce duplication of milling, stable product quality.
4. The device is fast to replace the roller sleeve, and liner, and reduce the downtime loss.
Principle of mining LM Series Vertical Mill
The motor drives the grinding table through decelerator. Hot air comes into the mill from the air inlet. The materials are pulverized by the roller when by pass of the groove on the grinding table. The coarse powder fall down the grinding table for regrinding under the function of rotation rotor. The fine powder comes out with the airstream,and is gathered by the dust catcher. By adjusting separator, it can reach proper fineness of materials.
parameter of mining LM Series Vertical Mill
Ore Mill
| Contents|Data//Model | LM130K | LM150K | LM170K | LM190K | LM220K | LM240K | |
| Disc Dia. (mm) | 1300 | 1500 | 1700 | 1900 | 2200 | 2400 | |
| Capacity (t/h) | 10~30 | 13~40 | 18~57 | 23~72 | 36~114 | 41~128 | |
| Output fineness | micron | 170~45 | 170~45 | 170~45 | 170~45 | 170~45 | 170~45 |
| mesh | 80~325 | 80~325 | 80~325 | 80~325 | 80~325 | 80~325 | |
| Product moisture | ≤1% | ≤1% | ≤1% | ≤1% | ≤1% | ≤1% | |
| Max.input size (mm) | <38 | <40 | <42 | <45 | <50 | <55 | |
| Best input moistrure | <4% | <4% | <4% | <4% | <4% | <4% | |
| input moistrure(drying required) | <15% | <15% | <15% | <15% | <15% | <15% | |
| Inlet air temperature (℃) | <350 | <350 | <350 | <350 | <350 | <350 | |
| Outlet air temperature (℃) | 70~95 | 70~95 | 70~95 | 70~95 | 70~95 | 70~95 | |
| Main mill power (KW) | 185~220 | 250~280 | 355~400 | 450~500 | 710~800 | 800~900 | |
| Dimension | Lmm | 3500 | 4200 | 4700 | 8500 | 10200 | 11700 |
| Wmm | 3400 | 3900 | 4500 | 5600 | 6700 | 7700 | |
| Gmm | 5800 | 7100 | 8300 | 8800 | 10600 | 12200 | |
| Weight (t) | 48 | 75 | 90 | 100 | 125 | 160 | |
Notes:
1. Material should be with hardness less than 7 in Mohs.
2. Hot air is only necessary if outlet moisture is required to be less than inlet moisture.
3.When grinding mateiral that is difficult to grind, please use the largest power.
Coal Mill
| Contents|Data//Model | LM130M | LM150M | LM170M | LM190M | LM220M | LM240M | |
| Disc Dia. (mm) | 1300 | 1500 | 1700 | 1900 | 2200 | 2400 | |
| Capacity (t/h) | 10~15 | 16~22 | 20~28 | 26~35 | 35~45 | 40~50 | |
| fineness (R0.08) | <15% | <15% | <15% | <15% | <15% | <15% | |
| Coal powder moisture | <1% | <1% | <1% | <1% | <1% | <1% | |
| Max.input size (mm) | <38 | <40 | <42 | <45 | <50 | <55 | |
| input moistrure | <15% | <15% | <15% | <15% | <15% | <15% | |
| Inlet air temperature (℃) | <350 | <350 | <350 | <350 | <350 | <350 | |
| Outlet air temperature (℃) | 75~95 | 75~95 | 75~95 | 75~95 | 75~95 | 75~95 | |
| Hardgrove index of raw coal (HGI) | >55 | >55 | >55 | >55 | >55 | >55 | |
| Main mill power (KW) | 185 | 250 | 315 | 400 | 500 | 560 | |
| Dimension | Lmm | 3500 | 4200 | 4700 | 8500 | 10200 | 11700 |
| Wmm | 3400 | 3900 | 4500 | 5600 | 6700 | 7700 | |
| H mm | 5800 | 7100 | 8300 | 8800 | 10600 | 12200 | |
| Weight (t) | 46 | 75 | 94 | 100 | 122 | 157 | |
