C140 42 x 55 inch Jaw Crusher

This equipment has the advantages of advanced technology, long service life, reliable work and easy maintenance. It is suitable for crushing all kinds of soft and hard ore materials with compressive strength not higher than 320MPa, and can be used for coarse, medium and fine crushing operations.


  • Materials Quartzite, pyroxene, iron ore, gold ore, copper ore, etc.
  • Application Mining, metallurgy, building materials, highway and other industries
  • Capacity 325 - 840 TPH
  • Output Size 150 - 375 mm

Product Details

Product Tags

The C140 Jaw Crusher innovatively adopts a deeply optimized crushing chamber design, which not only completely solves the problem of dead zone caused by the accumulation of materials, but also greatly promotes the smooth feeding of materials and efficient crushing, which significantly improves the efficiency. At the same time, this model has also made significant breakthroughs in energy saving and consumption reduction, when the single machine can reduce energy consumption by 15% to 30%, and if placed in the entire production system, its energy-saving efficiency can be doubled, providing strong support for the sustainable development of enterprises.



C140 42 x 55 inch Jaw Crusher Applications

As an efficient and reliable crushing equipment, C140 42 x 55 Jaw Crusher has demonstrated its excellent performance and wide application value in many industrial fields. This crusher has won wide recognition in the market for its large crushing ratio, high capacity, even distribution of finished products as well as simple structure and reliable performance.
The C140 42 x 55 Jaw Crusher plays a vital role in the mining industry. It is mainly used for medium size crushing of various ores, especially for materials with compressive strength not exceeding 320MPa, such as iron ore, gold ore, copper ore, etc. Its high efficient crushing capacity and stable performance greatly improve the processing efficiency of ores and reduce the production cost. In addition, the wearing parts of this crusher, such as the fixed and swinging jaw plates, are made of high manganese steel or high chromium steel, which have good wear resistance and impact resistance, further extending the service life of the equipment.
In the building materials industry, the C140 42 x 55 Jaw Crusher also has a wide range of applications. Whether it is limestone, gypsum, or other building materials that are crushed and processed, this crusher can handle it with ease. Its precise crushing effect and uniform finished product size ensure the high quality of construction materials and meet the high standard of raw materials required by the construction industry. At the same time, the efficient operation of the crusher also improves the overall efficiency of the building materials production line, creating greater economic benefits for the enterprise.
Crushed stone is an indispensable building material in the construction of highway and railroad. the C140 42 x 55 Jaw Crusher is able to efficiently crush large stone into a particle size that meets the construction standard, providing high quality aggregates for the paving of highways and railroads. Its stable performance and efficient crushing capacity ensures the smooth construction of the project, and at the same time reduces the construction cost and improves the quality of the project.
In water conservancy and chemical industry, C140 42 x 55 Jaw Crusher also plays an important role. In the water conservancy project, the crushed stone can be used in the construction of embankment, bank protection and other structures; in the chemical industry, the crushed material can be used as raw material or filler. The wide application of this crusher not only improves the utilization rate of raw materials, but also promotes the sustainable development of related industries.



C140 42 x 55 inch Jaw Crusher Advantages

Advanced technology and long service life

First of all, it is reflected in its advanced manufacturing process, which ensures the excellent performance and long service life of the equipment. Its robust and durable structural design enables the equipment to maintain stable and reliable performance even under high load working environment, providing a solid guarantee for the continuous operation of the production line.

Reliable operation

In addition, the reliability of the equipment in the work is also one of its distinguishing features, can effectively reduce the production loss caused by the failure of downtime. The easy maintenance further reduces the maintenance cost of the equipment, reduces the downtime and improves the overall production efficiency.

Easy maintenance

C140 Jaw Crusher also excels in crushing capacity, it is especially suitable for handling all kinds of soft and hard ore materials with compressive strength not exceeding 320MPa, whether coarse crushing, medium crushing or fine crushing, it can easily cope with different production needs. This wide range of applicability, making the equipment in mining, metallurgy, building materials and other industries are widely welcomed and recognized.



C140 42 x 55 inch Jaw Crusher Working Principle

The C140 Jaw Crusher, with a size of 42x55 inches, works on a principle inspired by the mechanism of jaw movement in the biological world, by simulating this natural process to achieve the crushing of materials. Specifically, the electric motor is used as the power source to drive the belt and pulley to rotate, which in turn leads the up and down reciprocating motion of the jaw through the eccentric shaft. When the movable jaw is in the rising state, the angle between it and the elbow plate gradually increases, which pushes the movable jaw plate to move towards the stationary fixed jaw plate, and carries out various forms of crushing treatment for the materials clamped between the two jaws, including extrusion, rubbing, grinding, etc. Subsequently, during the descending process of the movable jaw, the material is crushed and crushed. Subsequently, during the descent of the movable jaw, the angle decreases, and the movable jaw plate retreats with the assistance of the spring and the tie rod, releasing the crushed materials, which are then automatically slid down to the discharge port at the lower end of the jaw cavity to complete the discharge under the action of gravity. With the continuous operation of the motor, this cycle of crushing and discharging is repeated to ensure efficient and continuous crushing of materials.



C140 42 x 55 inch Jaw Crusher Technical Parameters



Metso C140 jaw crusher Available for inspection or shipment Available for inspection or shipment Includes flywheels and guarding
Operated at a cement facility crushing limestone Recently serviced before shutdown 250 HP motor 1200 RPM
 460 V TEFC Feed opening 42 x 55 inches (1 x 1.4 meters)
Maximum accepted Feed Size 33 inches Closed side setting range 4 - 10 inches (150 - 375 mm)
Throughput 325 - 840 TPH Motor Power 200 kW (250 HP)
Crusher RPM 220
