Jaw Crusher
Jaw Crusher can be used as the rock crusher, specialized design for ore mine, smelting, building materials, highway, railway, water conservancy, quarry, road building, etc, industrial department.
Features of jaw crusher:
High ratio of crushing with epigranular finished product; easy change of parts with little safeguard work; simplicity structure with reliable performance, which lower the running cost; low noise and little dust; range adjustment of layout, which can meet different customers.
Working principle of jaw crusher:
The motor drives the belt and belt pulley to make the moving jaw move up and down through eccentric axis. When the moving jaw rises, the intersection angle between the scale board and moving jaw becomes large, thus drives moving jaw approach the fixed board, and simultaneously, the material is crushed or chopped to achieve the destination of crushing. When the moving jaw drops, the angle becomes small, moving jaw board is away from the fixed board under the function of draw bar and bearing, meantime, the crushed material is laid out from the cavity.
Impact crusher
Impact crusher can handle with the material which is of coarse, medium and fine with the length no more than 500 mm, pressure-resistant no more than 350MPa, it is widely used in water and electricity, expressway, artificial sand & stone material, crushing industry, etc.
Features of impact crusher:
Unique structure with seamless welding plus the high-chromium hammer with counterattack lining board; High efficiency and power saving when dealing with the hardware; cubic like of end product with adjustable granularity of finished product, which makes the crushing process easier.
Working principle of impact crusher:
The rotor is at a high speed revolution driven by the electric motor, and when the material is entering the cavity, the plate hammer is striking with the material for crushing and then the material is striking back to crush again, finally the material ejects from the layout, which becomes the finished product.
