Introduction:
YGM Series Suspension Mill is a type of high pressure suspension mill.Which makes the grinding industry high efficiency and low energy consumption. It combines actual conditions of application of grinding equipments. High Pressure Suspension mill is mainly made up of the mainframe, separator, blower, finished powder cyclone collector, bag filter and connecting pipes, etc.
Products features :
- Its capacity increases by 10%-20% under the same power condition .
- Some size of final product can reach the fineness of 0.013mm (1000 mesh).
- High Pressure Suspension Mill put out less pollution . It saves energy at the same time .
- Low operation cost. Green. The effect of dust removing reaches to state standard.
- The multi-class seals are adopted to keep the grinding equipment tightly closed.
Working principle:
When the materials are sent into the grinding chamber, they are brought to the space between the roller and ring and get grinded. The fine powder after departed with the air is discharged through the outlet as final product. The circular air returns back to the blower that the above process will be repeated, and the remaining air enters the bag filter in order to protect the environment. The process is to make sure the stable production and the fineness.
Technical data:
| Model | Piece of roller | Size of the roller (mm) | Size of the ring (mm) | Feed size(mm) | Fineness of powder (mm) | Capacity (t/h) | Motor power (kW) | Weight (without motor)(t) |
| YGM65 | 3 | Φ210×150 | Φ650×150 | ≤15 | 0.033-0.613 | 0.4-1.8 | 15 | 3.6 |
| YGM75 | 3 | Φ260×150 | Φ780×150 | ≤15 | 0.033-0.613 | 1-3 | 18.5 | 4.8 |
| YGM85 | 3 | Φ270×150 | Φ830×150 | ≤20 | 0.033-0.613 | 1.2-4 | 22 | 8 |
| YGM95 | 4 | Φ310×170 | Φ950×170 | ≤25 | 0.033-0.613 | 2.1-5.6 | 37 | 14 |
| YGM130 | 5 | Φ410×210 | Φ1280×210 | ≤30 | 0.033-0.613 | 2.5-9.5 | 75 | 24 |
