Overview of mining Raymond Mill
Raymond Mill get the perfect structure to deal with the grinding process of non-flammable and non-explosive materials , for example , gypsum, talc, calcite, limestone, marble, granite, kaolin, bentonite, bauxite, iron ore and feldspar, barite, dolomite . Medium and large Raymond mill made by Liming brand is widely used in metallurgy, building materials, chemical industry and mining to process powder.
Feature of mining Raymond Mill
1. Strong systematic characteristic . Driving system works quite smoothly and operates reliably.
2. The Raymond mill is featuring the stable transmitting and reliable function.
3. For daily maintenance, spare parts should be take care of , to ensure the durability of the whole equipment.
4. Main parts of Raymond mill machine are made with high quality steel structure .
5. The equipment is adopting “safe operation of equipment maintenance system” to save costs of your investment .
Principle of mining Raymond Mill
The flowchart of raw material being crushed and grinding to fine size is a well designed one . It aims to achieve the fineness of final product requirement of our customers . After primary crushing , materials are evenly and continuously transported into the grinding chamber for powder-processing. The set’s airflow system is under condition of negative and positive pressure.
parameter of mining Raymond Mill
Model | 3R2115 | 3R2615 | 3R2715 | 3R3016 | 4R3216 | ||
Roller | Number | 3 | 3 | 3 | 3 | 4 | |
Diameter (mm) | 210 | 260 | 270 | 300 | 320 | ||
Height (mm) | 150 | 150 | 150 | 160 | 160 | ||
Ring | Inside diameter (mm) | 630 | 780 | 830 | 880 | 970 | |
Height (mm) | 150 | 150 | 150 | 160 | 160 | ||
Maximum feed size (mm) | 15 | 15-20 | 15-20 | 15-20 | 20-25 | ||
Output size (mm) | 0.044-0.165 | 0.044-0.165 | 0.044-0.165 | 0.044-0.165 | 0.044-0.165 | ||
Power of main frame (kW) | 15 | 18.5 | 22 | 30 | 37 | ||
Fineness of final product (mm) | 0.165 | capacity (t/h) | 1.2-1.8 | 1.8-2.5 | 2.3-2.8 | 2.6-3.2 | 3.2-4.5 |
0.075 | 0.6-1.2 | 1.2-1.8 | 1.8-2.3 | 1.9-2.6 | 2.4-3.1 | ||
0.044 | 0.6-1.0 | 0.8-1.2 | 0.9-1.7 | 1-1.9 | 1.8-2.5 |
